ON – GRID SOLAR POWER PLANT
On-Grid Systems are solar photovoltaic systems that only generate power when the utility power grid is available. They must connect to the grid to function. They can send excess power generated back to the grid when you are overproducing so you credit it for later use. An on-grid or grid-tie solar photovoltaic system is when your solar photovoltaic system is connected to a utility source or electrical service provider. You pay for the amount of electricity you consume to the utility provider. These are simplest systems and the most cost effective to install. These systems will pay for themselves by offsetting utility bills in 3-4 yrs. Grid-tie solar systems use inverters that meet the requirements of the utility and must not emit noise that can interfere with electrical devices such as reception for television and must retain acceptable levels of harmonic distortion for quality of voltage and current output waveforms. On-grid solar systems are advantageous as the electricity is utilized by the owner during the day and any surplus is supplied to the grid; some utilities pay for this surplus electricity at a higher rate known as a Feed In Tariff (FIT). During the evenings, when solar electricity is not generated, electricity is drawn from the grid avoiding the need for costly battery banks
contact us
Material Details and Specifications
| Sl. No. | Item | Qty. | Make | Warranty | Remarks |
|
1 |
Solar PV Modules(Bi-facial) |
5KW |
Microtek/Adani Solar |
12 Years for complete product, 30 Years for efficiency |
535Wp- 575Wp- 9Nos. |
|
2 |
Solar Ongrid Inverter-5Kw |
01 No. |
Microtek |
10 Years replacement warranty | With online monitoring |
|
3 |
Solar Mounting Structure |
5KW |
Galvanized |
5 Years |
Made by GI sheet on CNC Machine |
|
4 |
Solar DC Wire copper flexible(Type-1) | As Required |
Polycab |
5 Years |
1core 4Sq.mm |
|
5 |
Solar AC Wire copper flexible(Type-1) | As Required |
Polycab |
5 Years |
2core 4Sq.mm |
|
6 |
Solar AC Distribution Box with Surge Protection device |
01 No. |
Assembled |
5 Years |
MCB- Havells SPD- Elmex |
|
7 |
Solar DC Distribution Box with Surge Protection devices |
01 No. |
Assembled |
5 Years |
SPD- Elmex |
|
8 |
Earthing Electrodes- 2Mtr. and Chemical bag 25Kg. |
03 Nos. |
GSI |
5 Years |
Copper bonded |
|
9 |
Copper Bonded Lightning arrestor |
01No. |
GSI |
5 Years |
|
|
10 |
PVC cable tray/PVC pipes/ cable ties/ Fasteners and accessories | As Required |
Reputed Brand |
5 Years |
|
|
11 |
Transportation/loading/ unloading/lifting |
As Required | |||
|
12 |
Installation, commissioning and Govt. Liasioning | As Required |
SOLAR PLANT PROPOSAL
|
Project Name |
5 KWP – Solar PV Solution – CAPEX |
||
|
Client Name |
Kiran |
||
|
Client Address |
Rohtak |
||
|
Product/Services |
|
||
|
Offer Date: |
04-07-2024 |
||
|
Reference |
Amit Brothers |
Project Details
|
Sr. No. |
Requirements |
Details |
|
1 |
Project Size |
5KW |
|
2. |
Project Type |
CAPEX |
|
3. |
Area Required |
|
|
4. |
Module Tilt Angle |
According to site |
|
5. |
Site Survey Status |
– |
Product Details
|
Sr. No. |
Description |
Specification |
Make |
Qty |
|
1 |
Solar PV Module |
535 WP |
Microtek (Half-cut Mono Parc Bifacial) |
9 |
|
2 |
Inverter & Communication |
Grid Tie Inverter 6 KW |
Microtek |
1 |
|
3 |
Structure |
GI Pre- Galvanized |
The Battery Hub |
Standard |
Cables & Accessories
|
Sr. No. |
Description |
Specification |
Make |
Qty |
Units |
Remarks |
|
4 |
MC4 Connectors Conduit, Fastener Etc |
As Per Requirement |
Standard Make |
As Per Design |
Set |
Branded |
|
5 |
ACDB |
1 PH. or 3 PH. |
Microtek |
1 |
Sets |
Or Other Branded |
|
6 |
DCDB |
6KW/ 1 PH. or 3 PH. |
Microtek |
1 |
Sets |
Or Other Branded |
|
7 |
AC Cable |
10-90 SQ.MM |
Bentex |
As Per Site |
Roll |
Or Other Branded |
|
8 |
DC Wire |
4-8 SQ.MM |
Microtek |
As per Site |
Roll |
Or Other Branded |
|
9 |
Lightning Arrester |
Copper Bonded 1MTR |
Standard |
1 |
Rod |
Standard Size |
|
10 |
Earthing Copper Bonded |
Copper Bonded 2-3 MTR |
Standard |
2-3 |
Rod |
Standard Size |
|
11 |
Installation & Commissioning |
Complete |
THE BATTERY HUB |
As per Site |
– |
– |
Commercial Terms
|
Sr. No. |
Description |
Amount (Rs) |
|
1 |
SUPPLY OF SOLAR POWER PLANT INCLUDING (SOLAR PANELS, SOLAR INVERTER, STRUCTURE AND BALANCE OF COMPONENTS) |
2,45,956 |
|
2 |
|
5 KW |
|
3 |
RATE PER KW |
49,191 |
|
4 |
GST AS PER ACTUAL |
34,044 |
|
5 |
TOTAL AMOUNT |
2,80,000 |
Payment Terms
|
Sr. No. |
Description |
Amount (Rs) |
|
1 |
Advance with Documents For UHBVN |
1,00,000 |
|
2 |
Structure, ACDB, DCDB, All Wires |
1,00,000 |
|
3 |
Solar Panels & Inverter |
50,000 |
|
4 |
After completion Net Meter Work |
30,000 |
|
|
Grand Total |
2,80,000 |
List of Documents
DHBVN Electric bill
Aadhar Card (DHBVN Account Holder)
Pan Card
Photograph
Land Ownership Proof (Land Registry or conveyance deed)
Registered Mail Id
Registered Mob No
Cancel Cheque or Bank Pass Book
Economic Analysis
|
Sr. No. |
Cost Analysis Sheet On-Grid System |
5 Kw |
|
1 |
Current Scenario |
On Grid System |
|
2 |
Average Per Unit Cost of Grid Electricity (INR) |
7 |
|
3 |
Estimated Unit Generate Per Day |
25 |
|
4 |
Total Unit Generated by per year 330 Days |
8,250 |
|
5 |
Total Saving per year (INR) |
57,750 |
|
6 |
Project Cost Without GST (INR) |
2,45,956 |
|
7 |
Subsidy Amount (INR) |
78,000 |
|
8 |
After Subsidy Project Cost (INR) |
1,67,956 |
|
9 |
Pay Back Period will be around, Months |
35 approx. |
|
10 |
After Payback Period per year Saving (INR) |
57,750 |
Note: –
25 Year with 5Kw Solar Power Plant Estimated Saving (Rs.14,43,750/-)
Government Subsidy*
|
Solar Plant Capacity (KW) |
Subsidy Calculation (as per govt.norms) |
Amount (INR)* |
|
5-10 Kw |
https://pmsuryaghar.gov.in/ |
Approx 78,000/- |
Note: –
Your CFA/subsidy claim approval depends on the successful inspection and commissioning of your rooftop solar energy plant. The process also involves pairing a new metering system with your plant. The final amount of solar subsidy in Haryana is calculated according to your total system size which has been approved by your local DISCOM authority or recommended by your empanelled solar vendor, whichever is lower.
Note * Information Source https://pmsuryaghar.gov.in/
Warranties Term
All Equipment Supplied by us shall carry original equipment warranty/guarantee terms.
The back-to-back warranties/Guarantee provided for components and workmanships are as highlighted below:
- SOLAR PANELS – Microtek or Other Same level Brand
- Product Warranty 12 years for Manufacturing defects on PV modules
- Performance Warranty Power degradation < 2.0% in first year <0.45% /year in 25-30 years
- SOLAR INVERTER – Microtek ONGRID Inverter
- 10 YEARS STANDARD REPLACEMENT WARRANTY
- SOLAR SYSTEM –Provider –The Battery Hub
- SERVICE WARRANTY – 5 YEAR
- EXPECTED LIFE- 30 YEARS
Validity of Offer
Legal Payment Terms:
The customer agrees to clear the payment in full within 30 days from the completion of the solar panel’s installation work. In the event of any delay in payment beyond the stipulated 30-day period, the customer shall be liable to pay interest on the outstanding amount at a rate of 12% per annum from the 31st day onwards. Failure to make payment within the agreed timeframe may result in legal action and additional costs incurred for debt collection. Any disputes regarding the payment or the quality of the installation work shall be resolved through arbitration or mediation as per the terms and conditions of the contract.
By engaging in our services, the customer acknowledges and accepts these payment terms and agrees to fulfil their financial obligations in a timely manner. “
Please note that it’s important to consult with a legal professional to ensure that your payment terms are in compliance with local laws and regulations, and to adapt them to your specific business needs and the terms of your contracts.
Warranty Does Not Cover
Damage, deterioration or malfunction resulting from accident, misuse, neglect, fire, lightning, or other acts of nature, unauthorized product modification, or failure to follow instructions supplied with the product.
Repair or attempted repair by anyone not authorized by producer
Causes external to the product, such as electric power fluctuations or failure or insufficient ventilation.
Freight costs
Removal, installation, and set-up service charges
There are no warranties, express or implied, which extend beyond the description contained herein including the implied warranty of merchantability and fitness for particular purpose. Envision Enterprises liability is limited to the cost of repair or replacement of the product.
THE BATTERY HUB shall not be liable for:
Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
Any other damages, whether incidental, consequential or otherwise
Any claim against the customer by any other party.
Company Bank Details
|
Name |
THE BATTERY HUB |
|
Bank A/c No. |
16540200002944 |
|
Bank Name |
FEDERAL |
|
Branch Name |
Opp. Police Line, Rohtak, Haryana, 124001 |
|
IFSC Code |
FDRL0001654 |
|
GST No. |
06DEMPS0262F1ZG |
|
Company Address |
OPP. Rajiv Gandhi Stadium, H.no 1, Sector 6, Rohtak Haryana-124001 |
Copyright Notice
The attached quotation documentation (drawings, plans, program and test procedure description, etc.) remains the property of THE BATTERY HUB and must be returned immediately if no delivery contract be entered into. It is not permitted to pass on or duplicate the documentation, or to use or make public its content. Infringements of copyright will entail indemnity, even in the case of violations of the law committed by employees or authorized representatives.
All rights in the case of granting of a patent or of model registration reserved.
